Spesifikasi Produk
| Topologi | On-line double conversion system with PFC and ESS mode |
| Konfigurasi | Rack / Tower (3U Compact Design) |
| Rate (VA / Watt) | 15KVA / 15KW (9SX15K) & 20KVA / 20KW (9SX20K |
| Dimensi (tinggi x lebar x tebal, mm) | 129 x 438 x 589 |
| Koneksi | Terminal Block |
| Rentang Input Tegangan | 160V – 300V (Full Load); 100 - 160V linear derating |
| Tegangan Nominal | 1 phase 220/230/240V ; 3 phase 380/400/415V |
| Frekuensi | 50/60Hz |
| Rentang frekuensi | 40 Hz - 70 Hz |
| Wadah Output | Terminal Block |
| Frekuensi Output | 50/60Hz |
| Antarmuka | Touchscreen color LCD display (with gravity sensor) |
| Kebisingan | ≤55dB |
| Suhu Pengoperasian | 0°C ~ 50 °C (0~40 no derating，40°C~ 50°C derating to 50%) |
| Tanda keamanan | CE/TLC/RCM |
| Tanda EMC | CQC |
| License | CE / TLC / RCM / CQC |
