Product Specification
| Topology | On-line double conversion system with PFC and ESS mode |
| Configuration | Rack / Tower (3U Compact Design) |
| Rate (VA / Watt) | 15KVA / 15KW (9SX15K) & 20KVA / 20KW (9SX20K |
| Dimensions (height x width x depth, mm) | 129 x 438 x 589 |
| Connection | Terminal Block |
| Input Voltage Range | 160V – 300V (Full Load); 100 - 160V linear derating |
| Nominal Voltage | 1 phase 220/230/240V ; 3 phase 380/400/415V |
| Frequency | 50/60 Hz |
| Frequency Range | 40 Hz - 70 Hz |
| Output Receptacle | Terminal Block |
| Output Frequency | 50/60 Hz |
| Interface | Touchscreen color LCD display (with gravity sensor) |
| Noise heard | ≤55dB |
| Operating Temperature | 0°C ~ 50 °C (0~40 no derating，40°C~ 50°C derating to 50%) |
| Security sign | CE/TLC/RCM |
| EMC sign | CQC |
| Approval | CE / TLC / RCM / CQC |
