Eaton 91PS and 93PS (8-40kW)

Share this product

Product Specification

Number of internal batteries 0 or 1 x 32 blocks
Upgradability Yes, to 10 kW
External paralleling Up to 4 units with HotSync technology
UPS topolog Double conversion, 3-level IGBT converters
Efficiency in double-conversion mode 96%
Efficiency in Energy Saver System (ESS) mode1 Up to 99%
UPS dimensions (width x depth x height) 335 x 750 x 950 mm
UPS Degree of protection IP 20
Acoustic noise at 1 m, in 25 °C ambient temperature < 54 dBA in double conversion < 47 dBA in ESS
1000 m (3300 ft) above sea level at 40 °C Maximum 2000 m (6600 ft) with 1 % derating per each add. 100 m < 54 dBA in double conversion < 47 dBA in ESS
Input Voltage: 3:1 220/380V; 230/400V; 240/415V 1:1 220 V; 230 V; 240 V
Rated input frequency 50 or 60 Hz, user configurable
Frequency tolerance 40 to 72 Hz
Input power factor 0.99
Internal backfeed protection Yes, for rectifier and bypass lines
Battery technology 12 V, VRLA
Nominal Ah capacity (C10) 9Ah
Battery design life 5 years
Battery quantity: Internal External 32 blocks, 192 cells per battery string 28-40 blocks per string
Battery voltage: Internal External 384 V 336 V – 480 V
Charging method ABM technology or Float
Charging current limit Default 5A, configurable Maximum 12.5A
Battery start option Yes
Alternative energy source technologies Alternative energy source technologies
Network/SNMP interface Network/SNMP interface
Safety (CB certified) Safety (CB certified)
EMC IEC 62040-2
