Product Specification
| DIAGNOSTICS | Full system self-test at startup |
| UPS BYPASS | Automatic on overload or UPS failure |
| PARALLEL FOR REDUNDANCY | Yes, using Powerware Hot Sync technology and capacity |
| OVERLOAD (NORMAL OPERATION) | 150% for 5 sec / 125% for 1 min (online), 110% for 10 min |
| NOMINAL INPUT VOLTAGE | 9355 (10 - 15 kVA): |
| INPUT VOLTAGE RANGE | -15%, +10% from nominal at 100% load without depleting battery |
| OPERATING FREQUENCY | 50/60 Hz (45 to 65 Hz) |
| INPUT POWER FACTOR | >0.99 typical, >0.96 frequency converter |
| INPUT CURRENT DISTORTION | 5% THD |
| NOMINAL OUTPUT VOLTAGE | 208/120, 220/127 Vac |
| OUTPUT VOLTAGE REGULATION | ±1% static; ±5% dynamic at 100% resistive load change, <1 ms response time |
| EFFICIENCY | 91%, typical |
| BATTERY TYPE | 9 Ah, sealed, lead-acid, maintenance-free |
| BATTERY MANAGEMENT | ABM technology |
| BATTERY REPLACEMENT | Field-replaceable |
| START-ON-BATTERY | Allows start of UPS without utility input |
| LCD DISPLAY | Graphical LCD with blue backlight |
| AUDIBLE ALARMS | Yes |
| COMMUNICATION PORTS | (1) RS-232, (1) relay contact, (1) REPO, (2) environmental input |
| COMMUNICATION SLOTS | (2) X-Slot communication bays |
| POWER MANAGEMENT SOFTWARE | Bundled software suite CD |
| OPERATING TEMPERATURE | 50–104ºF (10–40ºC), 45ºC with 7.5% derating; Optimal battery performance: 77ºF (25ºC) |
| STORAGE TEMPERATURE | 32–77ºF (0–25ºC); Recommended battery storage: 59–77ºF (15–25ºC) |
