Eaton 93E UPS 15-500 kVA

Eaton 93E 200kVA 180KW 400V/230V nominal (380Y/220V, 415Y/240V)50 Hz (50/60 Hz programmable) 96% ABM technology 5”LCD APAC

Share this product

Product Specification

POWER RATING 20-60 kVA
VOLTAGE 208/220 Vac Three-phase
FREQUENCY 50/60 Hz
TOPOLOGY Double conversion online with Multi-Mode (High efficiency)
EFFICIENCY 98% in high efficiency mode
CONFIGURATION Tower
BATTERIES Internal batteries up to 60 kVA External batteries up to 400 kVA
ELECTRICAL INPUT 208/120V, 4 wire 220/127V, 4 wire
VOLTAGE RANGE +20% / -15% at 208V with 100% load without depleting battery
OPERATING FREQUENCY 50/60 Hz (40 to 72 Hz)
POWER FACTOR > 0.99 typical
INPUT CURRENT DISTORTION 5% THD
REGULATION ±1% static, ±5% dynamic at 100% resistive load change, <20 ms response time
BATTERY TYPE 9 AH, sealed, lead-acid, maintenance free
BATTERY RUNTIME (100% LOAD) 20 kVA - 21 minutes 30 kVA - 12 minutes 40 kVA - 10 minutes 60 kVA - 5 minutes
CHARGING METHOD ABM or float technology

Battery Runtime

Battery runtimes are approximate and may vary with equipment, configuration, battery age, temperature, etc. Actual runtime may vary from +/- 15% around these typical values
