Eaton 93PR (25-200 kW)

Eaton 93PR UPS, 1342S ETN TB 200K 400,380/400/415 PB WME

Categories: ,
Share this product

Product Specification

UPS output power rating (1.0 p.f.) 500, 600 kW
Efficiency in double conversion mode Up to 97.5%
Efficiency in Energy Saver System (ESS) Up to 99%
Parallel capability Maximum 8 units external parallel
Cold start Supported
Soft start Rectifier ramp up, compatible with generator, ramp up rate configurable
Voltage 380/400/415 V
Voltage range 301~478V L-L | 175~276V L-N
Frequency range 50/60 Hz
Input power factor > 0.99
Input current distortion < 3% @ 100% load capacity
Voltage 380/400/415V, 4 wire
Frequency range 50/60 Hz
Total VHD < 1% (100% linear load); < 3% (100% non-linear load)
Overload 125% 10 mins
Battery type Lithium, VRLA, Ni-Cad
Charging method BMS, ABM or constant float charge
Battery voltage 360~640 Vdc
Battery connection Support common battery
Weight without UPM 766 kg
UPM Weight 766 kg
UPM Weight 39 kg
UPS dimension (H x D x W) UPS dimension (H x D x W)
UPS dimension (H x D x W) UPS dimension (H x D x W)
