Product Specification
| POWER RATING | 8-15 kVA at 0.9 power factor |
| VOLTAGE | 200-240 VAC with neutral or with optional input transformer |
| FREQUENCY | 50/60 Hz |
| TOPOLOGY | Double conversion |
| CONFIGURATION | Compact tower |
| RATING (VA/WATTS) | Up to 15000/13500 |
| UPS BYPASS | Automatic on overload or UPS failure |
| EFFICIENCY | Up to 91% |
| CONNECTION | Hardwired - see manual for terminal block layout |
| FREQUENCY RANGE | 45 to 65 Hz |
| INPUT POWER FACTOR | P.F >0.99 typical, >0.96 frequency converter |
| OUTPUT VOLTAGE | 100/200, 110/220, 120/240 Vac 180° phase displacement; 120/208, 127/220 Vac 120° phase displacement |
| ON UTILITY VOLTAGE REGULATION | Output voltage regulation ±1% Static; ±5% dynamic at 100% resistive load change |
| OVERLOAD CAPACITY | 150% for 5 sec / 125% for 1 min (online), 110% for 10 min |
| BATTERY MANAGEMENT | ABM technology |
| BATTERY TYPE | 9Ah, sealed, lead-acid, maintenance-free |
| BATTERY REPLACEMENT | Field-replaceable |
| USER INTERFACE | LCD Display with blue backlight |
| LEDS | (4) LEDs for notice and alarm |
| COMMUNICATION PORTS | (1) RS-232, (1) relay contact, (1) REPO, (2) environmental input |
| COMMUNICATION SLOT | (2) X-Slot communication bays |
| AUDIBLE NOISE | <53dBA at 1 meter (noise less room) typical |
| OPERATING TEMPERATURE | 10°C to +40°C, +45°C with 7.5% derating; Batteries recommended max. +25°C |
| STORAGE TEMPERATURE | -15°C to +25°C |
| RELATIVE HUMIDITY | 0-95%, non condensing |
| SAFETY CERTIFICATIONS | UL1778 5th Edition, CSA C22.2 No. 107.3-14, NOM-NYCE |
