Product Specification
| Power Level | 500/600 kW |
| Efficiency in double conversion mode (full load) | 400/230V, 4 wire (380/415V selectable) |
| Efficiency in double conversion mode (half load) | -15%, +20% from nominal (400 V) at 100% load without depleting battery |
| VMMS (double conversion) | 50/60 Hz (40 to 72 Hz) |
| Efficiency in Energy Saver System (ESS) | >0.99 typical |
| Distributed paralleling with Hot Sync technology | ≤5% THD |
| Internal N+1 redundance capable | 400/230V, 4 wire (380/415V selectable) |
| Field upgradeable | -15%, +20% from nominal (400 V) at 100% load without depleting battery |
| Inverter/rectifier topology | 50/60 Hz (40 to 72 Hz) |
| Audible noise | >0.99 typical |
| Altitude (max) | ≤5% THD |
| Input wiring | 3 ph + N + PE |
| Nominal voltage rating (configurable) | 220/380, 230/400, 240/415 V 50/60 Hz |
| Input frequency range | 45-65 Hz |
| Input power factor | 0.99 |
| Input ITHD | < 3% on nominal load in double conversion mode |
| Soft start capability | Yes |
| Internal backfeed protection | Yes, standard |
| Output wiring | 3 ph + N + PE |
| Output UTHD | <2% (100% linear load); <5% (non linear load) |
| Battery Type | VRLA, AGM, Gel, Wet Cell |
| Charging method | Current limited constant voltage charging, or Eaton Advanced Battery Management (ABM) |
| Temperature compensation | Optional |
